Function

Punching Marking and shearing

Model

JX2020

JX1412

JX90

JX70

Angle Size(mm)

Max Punching capability(D x T)

Q345

45*45*4-200*200*20

40*40*3-140*140*12

40*40*3-90*90*9

35*35*3-70*70*7

Max punching force(diameter*thickness/mm)

Q345

φ26*20

φ26*12

φ26*8

φ22*6

Punching Nominal Force(KN)

1000

630

400

200

Marking Nominal Force(KN)

700/1000

700/1000

700

700（选配项）

Cutting Nominal Force (KN)

1600（Double shearing

）

4000（Single shearing）

900（Double shearing

）

1600（Single shearing

）

630（Single shearing）

450（Single shearing)

Max  Work piece  Length(m)

14

12

12

9

Adjustment  range of Stadim(mm)

20-170

18-110

18-60

17-46

Punchers number In Each side

3

2/3

2

1

Marking Groups

4（each group 12/8）

12（option)

Dimension of Character (mm)

14*10*20

Shearing Mode

Double-blade cutting

Double-blade cutting

Single blade cutting

Single blade cutting

CNC Axes Number

3

1

In feed  speed

0-60无级可调

Overall dimension

32*7*2.6

23*7*2.4

22*6*1.8

17*6*1.6

Net Weight(kg)

20000

16000

13000

7000
